8 inch 3mm Front Bezel Industrial Android Panel PC
Size:7”~8”
Industrial Android tablet PC with 3mm thin front bezel excellent for embedding into cabinets and equipment. Built with industrial electronic components, effectively prevent external electromagnetic interference.
| Quick Details: | |||
| CPU | RK3568 | DDR | 2G/4G |
| EMMC | 16G/32G/64G | Panel size | 8″ |
| Touch Type | Capacitive/Resistive | Brightness | 300nits |
| Material | Aluminum Alloy | IP Grade | Front IP65 |
Product Details
Features:
- 1.Front bezel aluminum alloy brushed metal craft, seamless design, front panel IP65 waterproof.
- 2.The whole machine is made of aluminum alloy and sheet metal.
- 3.Industrial LCD panel, wide viewing angle, high nits, true color.
- 4. Adopt multi-points PCAP touch panel, high sensitive and fast-response. Covered with 3mm tempered glass for vandalproof.
- 5. High performance motherboard, 7×24 continuous operation.
- 6. Supports RTC real-time clock, scheduled power on and off, network wake-up, and RS232 serial port centralized control.
- 7. Ultra-thin front bezel 3mm, ideal for embedded mounting.
| Display parameters | Touch parameters | |||||
| LCD Size | 8” | Touch Types | Capacitive(G+G) | |||
| Active Area | 162.048（H）*121.536（V）mm | Clicks | Capacitive＞50 million times | |||
| Resolution | 1024*768 | Surface hardness | 7H | |||
| Contrast Ratio | 1000:1 | Touch Point | 10 points | |||
| Picture Aatio | 4:3 | Type of glass | Chemically strengthened glass | |||
| Viewing Angle | 85/85/85/85(Typ.)(CR≥10) | Transmittance | ＞85% | |||
| Response Time | 30ms | Power consumption | ||||
| Backlight Type | E-LED | Standby power（w） | ≤0.5W | |||
| Brightness | 300cd/m2 | Power consumption（w） | ≤12W | |||
| Life span | 50000H | Supply Voltage（v） | DC12V/DC9-36V(Optional） | |||
| Protection Level | IP65 (front screen) | Audio output power | 4Ω*2W | |||
| Android solution | Dimensions | |||||
| Chip | RK3568 | Packing Size (mm) | TBD | |||
| CPU | Cortex-A53*4@2.0GHz | Product Dimensions(mm) | 223*182*52mm | |||
| GPU | Mali-G52 | Embedded hole size(mm) | 190*126mm | |||
| NPU | 1T | VESA mounting | 75*75mm | |||
| DDR | 2G/4G | Environment | ||||
| EMMC | 16G/32G/64G | Operating temperature | -10℃~60℃ | |||
| OS | Android 11.0 | Operating humidity | 10%～80% RH Non-Condensing | |||
| LAN | 10/100/1000M | Storage temperature | -20℃~70℃ | |||
| WiFi | 2.4G | Storage humidity | 10%~90% RH Non-Condensing | |||
| B/T | 4.2 | Other | ||||
| System upgrade | TF card、USB | Installation | embedded mounting screws（Standard） | |||
| Port parameters | wall mounting brackets ,desk stand holder（optional) | |||||
| External Connectors | RJ45*1,EARPHONE*1,HDMI*1,USB2.0*2(OTG/HOST,RS232*2,DC *1,TF Card *1,RS422 /RS485 (Optional） | Accessories | Power adapter*1 (12V4A), warranty card Power Cable*1 (AC 100-240V50/60Hz), Recessed clip*4 |
|||
| Graph Supported Format | Customization (optional) | 3G,4G, Webcam, RFID reader etc. | ||||
| Video format | MP4,MKV,WMV,MOV,FLV3 | Warranty | 1 year warranty | |||
| Picture format | BMP,JPEG,PNG,GIF | Certificate | CE, FCC, RoHS | |||
