Techtion 17″ High Brightness Industrial Touch Display TS-170MCBX

We are pleased to introduce the latest industrial-grade display solution from Techtion Smart — the TS-170MCBX 17-inch Capacitive Touch Monitor. Engineered specifically for demanding outdoor and industrial environments, this product combines exceptional visual performance with robust hardware design to ensure your projects operate reliably and efficiently under the harshest conditions.

Key Features:

17-inch 5:4 aspect ratio screen with 1280×1024 resolution
1500 nits ultra-high brightness panel with OCR optical bonding technology
Full IP65-rated enclosure with aviation-grade connectors for superior dust and water resistance
High-performance EETI capacitive touch solution supporting glove and wet-hand operation for responsive and convenient use
Front-facing waterproof OSD buttons and brightness adjustment knob for easy, flexible control

Applications:

Suitable for maritime vessels, port terminals, oilfield equipment, outdoor construction machinery, military, security vehicles,etc.

Product Parameters：

Model: TS-170MCBX
Product type: Industrial Monitor
Resolution: 1280*1024
Viewing angle: 89/89/89/89(Typ.)(CR≥10)
Product Dimension (mm): 407.0*359.0*46mm
Brightness: 1500 cd/m²
Touch Type: Capacitive(G+G)-Optical Bonding
Surface Hardness: 7H
Life Span: 50000H
Touch Point: 10 Points
IP Rating: IP65
Operating Temp: -20°C to 70°C
Interfaces: VGA IN*1，HDMI IN*1，DC12V*1,Touch USB*1
VESA(mm): 75*75/100*100mm

To learn more about the product,please click on the video:

https://youtu.be/ZUn_kMpVl7w?si=sfBZm09sq63K9xdI

Please feel free to reach out for more information or to schedule a product demo. We look forward to collaborating with you.
